Stable Operation And High Output
Single-layer Blown Film Machine
The production line of single-layer blown film machines produced by PLASTAR is suitable for blowing high and low-pressure polyethylene. The products are widely used in packaging film, agricultural covering film, degradable film, clothing bag film, etc.
While optimizing the output, this unit adopts pulse heating to reduce or eliminate the use of cooling fans and maximize the utilization of heat energy. As a result, the output is increased and the energy consumption is decreased.
Forced feeding main machine
All main machines of PLASTAR adopt dual-alloy forced-feeding screws that feature excellent hardness and wear resistance. It can still plasticize a large number of particles under the environment of high speed and high pressure. The service life can reach 3-5 times of ordinary screws.
Cone stacking mold
The production line of single-layer co-extrusion blown film machines adopts a single-layer cone mold. We optimize the layout by virtue of thermofluidics and observe the fluid condition with the help of 3D simulation software. We are sure that after a high degree of polishing and coating, each runner has the ability to clean itself under the high pressure and high speed scouring of PLASTAR’s high-speed screws. It will reduce waste in the particle replacement process and shorten the downtime of maintenance.
Advanced automation module
The production line of single-layer co-extrusion blown film machines has advanced automation functions, such as centralized feeding, batching, weight control, and automatic central winding. All functions are integrated on the touch screen, thus simplifying operations and increasing productivity.
| Model | SD-55 | SD-60 | SD-65 | SD-80 |
|---|---|---|---|---|
| Suitable Material | HDPE / LDPE / LLDPE | |||
| Film Width | 800 mm | 1000 mm | 1200 mm | 1500 mm |
| Film Thickness | 0.08 - 0.15 mm | 0.08 - 0.15 mm | 0.08 - 0.15 mm | 0.02 - 0.2 mm |
| Max. Output | 55 - 60kg / h | 75 - 80kg / h | 130kg / h | |
| Extruder | ||||
| Screw Diameter | 55mm | 60mm | 65mm | 80mm |
| Screw L/D | 30:1 | |||
| Barrel Cooling | Water Cooling | |||
| Main Motor Power | 22kw | 30kw | 37kw | 45kw |
| Total Power | 48kw | 60kw | 55kw | 120kw |
| Die Head | ||||
| Die Head Type | Single Layer | |||
| Air Ring | Double lips air ring | |||
| Traction Roller Width | 900 mm | 1100 mm | 1300 mm | 1600 mm |
| Effective Width | 800 mm | 1000 mm | 1200 mm | 1500 mm |
| Traction Speed | 100 m/min | 100 m/min | 100 m/min | 80 m/min |
| Winding Unit | ||||
| Wingding Type | Friction type automatic single / double winder | |||
| Wingding Speed | 100 m/min | 100 m/min | 80 m/min | 60 m/min |
| Voltage | 380V, 50Hz | |||
| Dimension | 5000 * 2500 * 5000 mm | 5000 * 2500 * 6500 mm | 5000 * 2600 * 7000 mm | 7500 * 3200 * 8500 mm |
| Weight | 4 T | 5 T | 5.5 T | 7 T |
Video
Supermarket Flat Bags
Supermarket Flat Bags
Supermarket Flat Bags
Plastic Gloves
T-shirt Bags
Plastic Vest Bags
Plastic Vest Bags
T-shirt Bags
Plastic Gloves
Garbage Bags
Supermarket Flat Bags
Plastic Vest Bags
Plastic Vest Bags
200 kg Mixing Machine
Loss-in-weight Feeder
Corona Treatment Rack
Leftover Material Recovery Machine
Leftover Material Recovery Machine-with Feeder
Air Compressor
Suction Machine
Argentina - Single-layer Blown Film Extrusion Machine
In February 2018, An Argentina customer bought three SD-50 single-layer 600mm HDPE blown film machines.
Bolivia - Single-layer LDPE Blown Film Extrusion Machine
In October 2018, a Bolivian customer purchased two single-layer LDPE blown film extrusion machines.
Panama - Single-layer Blown Film Extrusion Machine
At the end of 2018, a customer successfully purchased the single-layer blown film extrusion machine SD-55-700, and the machine has been operating well in the customer’s factory.
-
A1.
The Monolayer Blown Film Extrusion machine, also known as a single-layer blown film extrusion machine, is a type of Blown film extrusion machine specifically designed to print continuous lengths of plastic pieces from a specific resin type and is commonly used to produce agricultural covering film, degradable film, clothing bag film, and many others.
If you want to blow high and low-pressure polyethylene, then you should consider the Monolayer Blown Film extrusion machine as it puts an end to the usage of cooling fans and helps you make the best use of heat energy, thereby increasing production output and conserving energy rate.
A monolayer blown film extrusion machine makes use of a single-layer cone mold and also equips each runner with the ability to clean itself during intense pressure, thereby reducing the presence of dirt in the particle replacement area.
The monolayer blown film extrusion machine is equipped with advanced automatic functions such as weight control, automatic central winding, batching, and a lot more, which have been merged with the touch screen to aid your printing process.
